- Place of Origin: Hebei Xingtai
- Brand Name: Xingtai First Tractor Manufacturing Co., Ltd.
- Model Number: XT304
Product details:
Machine parameters
Tractor Model XT304
Type 4 × 4 wheeled tractor
Rated traction force (kN) 7.5
Dimensions (length × width × height, mm) 2950 × 1280 × 1980
Build quality (kg) 1200
Use the smallest mass (kg) 1300
Wheelbase (mm) 1650
Tread (front / rear, mm) 1060/1020
Minimum ground clearance (mm) 320
The minimum turning radius (m) 4.5
Theoretical speed (km / h) advancing 2.21 / 3.37 / 5.3 / 7.3 / 10.25 / 15.68 / 24.51 / 33.81
Back 2.90 / 12.42
Ⅰ class suspension, rear three-point linkage
Non-independent PTO, clockwise, 540rpm, spline nominal outer diameter of 35mm
Tire model 6.00-16 / 9.5-24
Engine parameters
Engine Model TY2102T
Engine type vertical twin-cylinder, water-cooled, four-stroke diesel engine
12 hours power (kW) 22.1
Speed (rpm) 2400
Starting method electric start
Bore × Stroke (mm) 102 × 105
Fuel consumption (g / kW · h) ≤250
Oil consumption (g / kW · h) ≤2.04
- Place of Origin: Hebei Xingtai
- Brand Name: Xingtai First Tractor Manufacturing Co., Ltd.
- Model Number: XT304
